Technical data
 Rated supply voltage 220 – 240 V
 AC voltage range 198 – 264 V
 DC voltage range 176 – 280 V
 Input current (at 230 V, 50 Hz, full load)1 0.32 A
 Leakage current (at 230 V, 50 Hz, full load) < 450 µA
 Mains frequency 0 / 50 / 60 Hz
 Overvoltage protection 320 V AC, 2 h
 Output power range 18 – 65.1 W
 Typ. efficiency (at 230 V / 50 Hz / full load)1 93.5 %
 λ (at 230 V, 50 Hz, full load)1 0.98
 Output current tolerance3 ± 7.5 %
 Max. output voltage 320 V
 THD (at 230 V, 50 Hz, full load)1 < 10 %
 Max. peak output current at full load1 395 mA
 Output LF current ripple (< 120 Hz) at full load ± 5 %
 Output Pst LM (at full load) ≤ 1
 Output SVM (at full load) ≤ 0.4
 Starting time (at 230 V, 50 Hz, full load) ≤ 0.5 s
 Starting time (DC mode) ≤ 0.6 s
 Switchover time (AC/DC) ≤ 0.3 s
 Turn off time (at 230 V, 50 Hz, full load) ≤ 0.5 s
 Hold on time at power failure (output) 0 s
 Ambient temperature ta (at lifetime 50,000 h) 60 °C
 Storage temperature ts-40 ... +80 °C
 Mains burst capability 1 kV
 Mains surge capability (between L – N) 1 kV
 Mains surge capability (between L/N – PE) 2 kV
 Surge voltage at output side (against PE) 3.5 kV
 Lifetime up to 50,000 h
 Dimensions L x W x H 230 x 30 x 21 mm
 Hole spacing D 218 mm

Záruka 24 měsíců.

Certifikát CE, TUV.

Výrobek certifikován dle platných norem EU.
